The UniFi AC HD AP is the first UniFi 802.11ac Wave 2 AP. Combining the performance increases from MU-MIMO technology and the use of 4×4 spatial streams, the UniFi AC HD AP delivers up to 125% greater performance* than a typical Wave 1 AP.
For optimal performance, use MU‑MIMO clients. SU‑MIMO clients will also benefit and gain up to 10-20% greater performance when used with the UniFi AC HD AP.
Ubiquiti UniFi AC HD AP Key Features
- Simultaneous Dual-Band
- 800Mbps at 2.4GHz
- 1733Mbps at 5GHz
- 4×4 Multi-User MIMO
- Four-Stream 802.11AC Wave 2 Technology
- 802.3at PoE+ Compatibility
Deploy the UniFi AC HD AP in high-density environments requiring maximum wireless performance. The UniFi AC HD AP features simultaneous, dual-band, 4×4 MU-MIMO technology and convenient 802.3at PoE+ compatibility. It is available in single- and five‐packs.
802.11ac Wave 2 MU‑MIMO (Multi‑User, Multiple Input, Multiple Output) technology allows a Wave 2 AP to communicate with multiple clients at the same time – significantly increasing multi‑user throughput and overall user experience.
UAP AC HD Technical Specification
| UAP AC HD Specifications | |
|---|---|
| Dimensions | 220 x 220 x 48.1 mm (8.66 x 8.66 x 1.89″) |
| Weight With Mounting Kits |
700 g (1.54 lb 830 g (1.83 lb) |
| Networking Interface | (2) 10/100/1000 Ethernet Ports |
| Buttons | Reset |
| Power Method | Passive Power over Ethernet (48V), 802.3at PoE+ Supported |
| Supported Voltage Range | 44 to 57VDC |
| Power Supply | 48V, 0.5A PoE Gigabit Adapter |
| Power Save | Supported |
| Maximum Power Consumption | 17W |
| TX Power 2.4 GHz 5 GHz |
6-25 dBm 6-25 dBm |
| Antennas 2.4 GHz 5 GHz |
(2) Dual‑Port, Dual‑Polarity Antennas, 3 dBi each (2) Dual‑Port, Dual‑Polarity Antennas, 4 dBi each |
| Wi-Fi Standards | 802.11 a/b/g/n/ac/ac-wave2 |
| Wireless Security | WEP, WPA‑PSK, WPA‑Enterprise (WPA/WPA2, TKIP/AES) 802.11w/PMF |
| BSSID | Up to Four per Radio |
| Mounting | Wall/Ceiling (Kits Included) |
| Operating Temperature | ‑10 to 70° C (14 to 158° F) |
| Operating Humidity | ‑10 to 70° C (14 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| Advanced Traffic Management | |
| VLAN | 802.1Q |
| Advanced QoS | Per-User Rate Limiting |
| Guest Traffic Isolation | Supported |
| WMM | Voice, Video, Best Effort, and Background |
| Concurrent Clients | 500+ |
| Supported Data Rates (Mbps) | |
| Standard | Data Rates |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 450 Mbps (MCS0 ‑ MCS23, HT 20/40) |
| 802.11ac | 6.5 Mbps to 1.7 Gbps (MCS0 ‑ MCS9 NSS1/2/3/4, VHT 20/40/80) |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Datasheet | |
