Improved Noise Immunity
The Ubiquti PowerBeam 5AC Gen2 directs RF energy in a tighter beamwidth. With the focus in one direction, the Ubiquti PowerBeam 5AC Gen 2 blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Ubiquti PowerBeam 5AC Gen2 Key Features
- Frequency 5 GHz
- Range 25 km
- Highly Efficient Antenna Beam Performance
- Up to 450 Mbps Throughput
- Dedicated Wi-Fi Radio for Management
Ubiquti PowerBeam 5AC Gen2 – Technical Specifications
- Dimensions 420 x 420 x 230 mm (16.54 x 16.54 x 9.06″)
- Weight 2.22 kg (4.89 lbs)
- Power Supply 24V, 0.5A Gigabit PoE Adapter (Included)
- Max. Power Consumption 8.5W
- Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Supported Voltage Range 20 to 26VDC
- Operating Frequency
- Worldwide
- 2412 – 2462 MHz
- 5150 – 5875 MHz
- Gain 25 dBi
- Networking Interface (1) 10/100/1000 Ethernet Port
- Processor Specs MIPS 74Kc
- Memory 64 MB
- LEDs Power, Ethernet, (4) Signal Strength
- Channel Sizes
- PtP Mode 10/20/30/40/50/60/80 MHz
- PtMP Mode 10/20/30/40 MHz
- Enclosure Characteristics
- Antenna Feed Outdoor UV Stabilized Plastic
- Dish Reflector Powder-Coated SPCC
- Mounting Pole-Mounting Kit (Included)
- Wind Loading 380 N @ 200 km/h (85.4 lbf @ 125 mph)
- Wind Survivability 200 km/h (125 mph)
- ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
- Operating Temperature -40 to 70° C (-40 to 158° F)
- Operating Humidity 5 to 95% Noncondensing
- RoHS Compliance Yes
- Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
- Vibration Test IEC 68-2-6
- Temperature Shock Test IEC 68-2-14
- UV Test IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
- Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
- Certifications CE, FCC, IC
