Ubiquiti Omni Antenna AirMAX MiMo 5GHz 13dBi, Omnidirectional Antenna -(AMO-5G13)

Manufacturer: Ubiquiti
Model: AMO-5G13

Ubiquiti Rocket M combines the “brains” in one robust unit; just pair Ubiquiti Rocket M with an Ubiquiti airMax Omni to create powerful 360° omnidirectional base station. This seamless integration gives network architects unparalleled flexibility and convenience.
Ubiquiti AMO-5G13 Key Features:

Frequency – 5 GHz
13 dBi Gain
Wind Survivability up to 125 mph
Plug-in and play integration
Product Model Number: AMO-5G13

Ubiquiti Omni Antenna AirMAX MiMo 5GHz 13dBi – Technical Specifications
Utilize Ubiquiti AirMax Technology*

Unlike standard WiFi protocol, Ubiquiti’s Time Division Multiple Access (TDMA) AirMax protocol allows each client to send & receive data using pre-designated time slots scheduled by an intelligent AP controller.

This “time slot” method eliminates hidden node collisions & maximizes air time efficiency. It provides many magnitudes of performance improvements in latency, throughput, & scalability compared to all other outdoor systems in its class.

Intelligent QoS – Priority is given to voice/video for seamless access.
Scalability – High capacity and scalability.
Long Distance – Capable of high speed Carrier Class links
Latency – Multiple features dramatically reduce noise.

Ubiquiti airMax Omni Antenna Technical Specifications (AMO-5G13)

Frequency Range: 5.45 – 5.85 GHz
Gain: 13 dBi
Elevation Beamwidth: 12 deg / 7 deg
Max VSWR: 1.6:1 / 1.5:1
Downtilt: 4 deg / 2 deg
Dimensions: (l x w x h) 158 x 98 x 579 mm / 158 x 98 x 834 mm
Weight: 0.68 kg / 0.82 kg
Wind Loading: 8 lb @ 100 mph / 10 lb @ 100 mph
Wind Survivability: 125 mph
Polarization: Dual Linear
Cross-pol Isolation: 25 dB min
ETSI Specification: EN 302 326 DN2
Mounting: Universal pole mount, Rocket M bracket and weatherproof RF jumpers included
