📦 Product Overview
The TP-Link CPE710 is a professional outdoor wireless CPE (Customer Premises Equipment) designed for long-distance point-to-point (PtP) and point-to-multipoint (PtMP) deployments.
With a high-gain 23dBi directional antenna and 802.11ac technology, it delivers high-speed, stable wireless connectivity over extended distances, making it ideal for ISPs, campuses, CCTV networks, and rural connectivity projects.
🔑 Key Features & Capabilities
🚀 High-Speed Wireless Performance
- 802.11ac (Wi-Fi 5) technology
- Speeds up to 867 Mbps on 5GHz band
- 256-QAM modulation for improved throughput (≈3× faster than 802.11n)
📡 Long-Range Transmission (Up to 30km)
- 23dBi high-gain directional antenna
- Designed for long-distance outdoor wireless links (up to 30 km)
- Narrow beamwidth for reduced interference and improved signal quality
🧠 Advanced RF Design
- 2×2 MIMO technology for better performance and stability
- Excellent noise immunity and latency reduction
- Adjustable transmission power (up to 27 dBm)
🌦 Outdoor-Ready Rugged Design
- IP65 weatherproof enclosure for harsh environments
- 15kV ESD protection & 6kV lightning protection
- Wind-resistant structural design for stability in outdoor installations
🔌 Flexible Deployment with PoE
- Powered via Passive PoE (16–27V DC)
- Simplifies installation by using a single Ethernet cable
- Suitable for pole mounting and outdoor installations
🧠 Centralized Management
- Managed via Pharos Control software
- Features:
- Device discovery
- Network monitoring
- Firmware upgrades
- Remote configuration
📊 Technical Specifications
| Feature | Specification |
|---|---|
| Wireless Standard | 802.11a/n/ac |
| Speed | Up to 867 Mbps |
| Frequency | 5 GHz |
| Antenna | 23 dBi Directional |
| Range | Up to 30 km |
| Ethernet Port | 1 × Gigabit RJ45 |
| PoE | Passive PoE |
| Protection | 15kV ESD, 6kV Lightning |
| Enclosure | IP65 Weatherproof |
| CPU | Qualcomm 750 MHz |
🛠 Ideal Use Cases
✅ Point-to-Point wireless bridges (building-to-building)
✅ Internet distribution in rural/remote areas
✅ CCTV surveillance network backhaul
✅ ISP wireless infrastructure
✅ Campus and enterprise outdoor networking
⭐ Why Choose the CPE710?
- Reliable long-distance wireless connectivity (up to 30km)
- High-gain antenna for stable signal transmission
- Durable design for harsh outdoor environments
- Cost-effective solution for wireless bridging instead of fiber
- Easy deployment with PoE and centralized management
🔗 Useful Links for Your Website
- 🌐 Official Product Page:
https://www.tp-link.com/business-networking/pharos-cpe/cpe710/ - 📄 Datasheet & Documentation:
Available under “Support” section on TP-Link product page - 🧠 Pharos Control Software (Management):
Available via TP-Link official website
