TP-Link EAP772 – BE9300 Tri-Band Wi-Fi 7 Omada Access Point

Overview

The TP-Link EAP772 is a next-generation Wi-Fi 7 (802.11be) tri-band access point designed for enterprise networks, offices, campuses, hotels, and high-density environments. It delivers ultra-fast wireless speeds of up to 9.3 Gbps, using the 2.4 GHz, 5 GHz, and new 6 GHz bands to provide faster connectivity and lower latency for modern devices.

Built for the TP-Link Omada SDN platform, the EAP772 enables centralized cloud management, seamless roaming, mesh networking, and AI-driven Wi-Fi optimization. With Wi-Fi 7 technologies like Multi-Link Operation (MLO) and 320 MHz channels, it significantly improves network efficiency and supports hundreds of simultaneous devices.

Key Features

Ultra-Fast Wi-Fi 7 Performance

The EAP772 delivers combined wireless speeds of up to 9.3 Gbps, ensuring smooth streaming, cloud applications, and high-bandwidth workloads.

Wireless Speeds:

• 6 GHz: up to 5765 Mbps

• 5 GHz: up to 2882 Mbps

• 2.4 GHz: up to 688 Mbps

This tri-band architecture reduces congestion and improves performance in high-density networks.

Wi-Fi 7 Advanced Technologies

The access point includes next-generation wireless innovations:

• Multi-Link Operation (MLO) for simultaneous multi-band connections

• 320 MHz channel bandwidth for higher throughput

• 4K-QAM modulation for faster data transmission

• OFDMA & MU-MIMO for efficient multi-device communication

These technologies deliver lower latency and higher network efficiency in busy enterprise environments.

High-Speed 2.5 GbE Connectivity

The device features a 2.5 Gigabit Ethernet uplink port, ensuring the wired network can fully support the high speeds of Wi-Fi 7 without bottlenecks.

Omada Cloud SDN Management

The Omada Software-Defined Networking (SDN) platform provides centralized network management and monitoring.

Management options include:

• Omada Cloud Controller

• Omada Hardware Controller

• Omada Software Controller

• Omada Mobile App

Key features include:

• Zero-touch provisioning

• Real-time monitoring and analytics

• AI roaming and seamless handoff between APs

• Mesh networking for extended coverage.

Wide Coverage and High Client Capacity

The EAP772 can cover approximately 140 m² (1500 ft²) and support 380+ connected clients, making it ideal for high-density wireless deployments.

Enterprise-Grade Security

Security features include:

• WPA3 encryption

• Captive portal authentication

• Rogue AP detection

• VLAN support

• Guest network isolation

These ensure secure enterprise Wi-Fi deployments for businesses and public networks.

Technical Specifications

Model: EAP772
Wi-Fi Standard: Wi-Fi 7 (IEEE 802.11a/b/g/n/ac/ax/be)

Wireless Bands

• 2.4 GHz, 5 GHz, 6 GHz (Tri-Band)

Maximum Speeds

• 6 GHz: 5765 Mbps

• 5 GHz: 2882 Mbps

• 2.4 GHz: 688 Mbps

Ports

• 1 × 2.5 GbE Ethernet port

Power

• 802.3at PoE+

• 12 V DC (optional)

Coverage

• Up to 140 m²

Concurrent Clients

• 380+ devices

Management

• Omada SDN Cloud Controller

• Web interface

• Omada mobile app

Mounting

• Ceiling or wall mounting

Ideal Use Cases

The TP-Link EAP772 Wi-Fi 7 Access Point is perfect for:

• Enterprise office networks

• Universities and campus networks

• Hotels and hospitality Wi-Fi

• Retail and shopping malls

• High-density environments

• Smart business networks

Why Choose TP-Link EAP772?

• Next-generation Wi-Fi 7 tri-band technology

• Ultra-fast 9.3 Gbps wireless speeds

• 2.5 GbE uplink for high-performance networks

• Omada cloud-managed networking

• Supports hundreds of simultaneous users

• Ideal for enterprise and high-density deployments
