TP-Link EAP110-Outdoor – 300Mbps Wireless N Outdoor Access Point

Overview

The TP-Link EAP110-Outdoor is a reliable 300 Mbps outdoor wireless access point designed to deliver stable Wi-Fi coverage in outdoor environments such as campuses, hotels, parks, warehouses, farms, and outdoor events.

Built with high-power wireless transmission and dual external antennas, the device provides long-range connectivity of up to 200 meters in open outdoor environments, making it ideal for extending Wi-Fi beyond indoor spaces.

The access point features an IP65 weatherproof enclosure, protecting it from dust, rain, and harsh environmental conditions. With Passive PoE support and flexible wall or pole mounting, installation is simple and cost-effective for outdoor wireless networks.

Key Features

Long-Range Outdoor Wi-Fi Coverage

The EAP110-Outdoor delivers up to 300 Mbps wireless speed using 2×2 MIMO technology, providing reliable connectivity for outdoor users and devices.

• Wireless speed up to 300 Mbps

• 2×2 MIMO technology

• Coverage up to 200 m outdoors

This makes it suitable for large outdoor areas requiring stable Wi-Fi connectivity.

Durable Weatherproof Design

The access point is built with a rugged IP65 weatherproof enclosure that protects it against harsh outdoor conditions including dust, rain, and humidity.

Key environmental protections include:

• Weather-resistant housing

• Lightning and ESD protection

• Reliable operation in outdoor environments

High-Gain External Antennas

The device features two detachable omnidirectional antennas designed for enhanced signal strength and wider coverage areas.

• 2 × external omni antennas

• Optimized for outdoor signal propagation

• Improved wireless penetration

Flexible Deployment with Passive PoE

The EAP110-Outdoor supports 24 V Passive PoE, allowing power and data to be delivered through a single Ethernet cable.

Benefits include:

• Simplified installation

• Reduced cable clutter

• Easy outdoor deployment

Omada Cloud Centralized Management

The access point integrates with TP-Link Omada SDN, enabling centralized management of multiple network devices through cloud controllers or mobile apps.

Management features include:

• Remote configuration and monitoring

• Network analytics and diagnostics

• Multi-site management

Advanced Wireless Security

The EAP110-Outdoor includes enterprise-level wireless security features such as:

• WPA/WPA2-Enterprise encryption

• VLAN support

• Guest network with captive portal

• Multiple SSID support (up to 8 networks)

Technical Specifications

Model: EAP110-Outdoor
Wireless Standard: IEEE 802.11b/g/n

Wireless Performance

• Frequency: 2.4 GHz

• Speed: Up to 300 Mbps

Ports

• 1 × 10/100 Mbps Ethernet (RJ45)

• Passive PoE support

Antennas

• 2 × detachable omni-directional antennas

Coverage

• Up to 200 m outdoor coverage

Security

• WPA-PSK / WPA2-PSK

• WPA/WPA2-Enterprise

• 802.1X authentication

Power

• 24 V Passive PoE

Weather Protection

• IP65 outdoor-rated enclosure

Dimensions

• Approx. 215 × 46 × 27 mm

Mounting

• Pole mount

• Wall mount

Ideal Use Cases

The TP-Link EAP110-Outdoor is ideal for:

• Hotels and resorts outdoor Wi-Fi

• Schools and campus networks

• Farms and agricultural networks

• Parks and recreational areas

• Warehouses and industrial yards

• Outdoor event Wi-Fi coverage

Why Choose TP-Link EAP110-Outdoor?

• Reliable long-range outdoor Wi-Fi coverage

• Weatherproof IP65 outdoor design

• Easy deployment with Passive PoE

• Centralized management with Omada SDN

• Ideal for large outdoor wireless networks
