Planet FGSW-1822VHP 16-Port 10/100TX 802.3at PoE + 2-Port Gigabit TP + 2-Port SFP Ethernet Switch with LCD PoE Monitor

26,100.00 KSh +VAT

16 10/100BASE-TX Fast Ethernet RJ45 copper ports

2 10/100/1000BASE-T TP and 2 1000BASE-X mini-GBIC SFP interfaces

Up to 16 ports of IEEE 802.3af/at devices powered

Resources

FGSW-1822VHP

Datasheet

Out of stock

PLANET FGSW-1822VHP

Plug and Watch

PLANET FGSW-1822VHP is an ideal Plug and Watch Power over Ethernet solution which provides quick installation, real-time PoE work status monitoring and immediate troubleshooting through its unique LCD display to improve work efficiency and quality without any PC or software required.
The Planet FGSW-1822VHP is equipped with 16 10/100BASE-TX ports with each port taking up 30 watts of PoE+ power and 2 Gigabit TP and 2 Gigabit SFP interfaces with inner power system. With a total PoE+ power budget of 300 watts and non-blocking data switching performance, the FGSW-1822VHP can fulfill the demand of sufficient PoE power for HD IP surveillance. It offers a desktop-sized, reliable and visible power solution for small businesses and system integrator deploying Power over Ethernet networks.

Smart and Intuitive LCD Control
PLANET FGSW-1822VHP provides an intuitive color panel on its front panel that facilitates the Ethernet management and PoE PD management. They greatly promote management efficiency in large-scale networks for enterprises, hotels, shopping malls, government buildings and other public areas.
PLANET FGSW-1822VHP feature the following special management and status functions:
■ PoE management and status
■ Port management and status
■ Switch mode: Standard, VLAN, Extend
■ Budget and bandwidth control
■ PD alive check
■ Maintenance: Screen saver, fan control, factory default and save configuration

PLANET FGSW-1822VHP Switching

Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Flow control for full duplex operation and back pressure for half duplex operation
9216bytes packet size
Integrates address look-up engine, supporting 8K absolute MAC addresses
IEEE 802.1Q VLAN transparency
Automatic address learning and address aging

PLANET FGSW-1822VHPHardware

19-inch desktop size, 1U height, rack mountable
2-inch color LCD with smart management functions
LED indicators for system power, per port PoE ready and PoE activity, speed, Link/Act
3 silent fans to provide stable and efficient power performance
Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Supports contact discharge of ±6KV DC and air discharge of ±8KV DC for Ethernet ESD protection
Supports ±6KV surge immunity
