MikroTik RB1100AHx4 Dude Edition
MikroTik RB1100AHx4 Dude Edition has Annapurna Alpine AL21400 CPU with four Cortex A15 cores clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbps. The device supports IPsec hardware acceleration and is faster at it than any previous RouterBOARD device (up to 2.2Gbps with AES128).
RB1100Dx4 Dude Edition Details | |
---|---|
Product code | RB1100Dx4 |
Architecture | ARM 32bit |
CPU | AL21400 |
CPU core count | 4 |
CPU nominal frequency | 1.4 GHz |
Dimensions | 443 x 148 x 44 mm |
License level | 6 |
Operating System | RouterOS |
Size of RAM | 1 GB |
Storage size | 128 MB |
Storage type | NAND |
Tested ambient temperature | -40°C to 70°C |
Powering
Details | |
---|---|
PoE in | 802.3af/at |
PoE in input Voltage | 20-57 V |
Number of AC inputs | 2 |
Number of DC inputs | 2 (2-pin terminal, PoE-IN) |
2-pin terminal input Voltage | -48, 20-57 V |
Max power consumption | 33 W |
Max power consumption without attachments | 25 W |
Ethernet
Details | |
---|---|
10/100/1000 Ethernet ports | 13 |
Peripherals
Details | |
---|---|
Extended storage | 60GB M.2 SSD included |
M.2 slots | 2 |
Memory card type | microSD |
Memory Cards | 1 |
SATA ports | 2x SATA3 |
Serial port | RS232 |
Other
Details | |
---|---|
Current Monitor | Yes |
PCB temperature monitor | Yes |
Voltage Monitor | Yes |
Certification & Approvals
Details | |
---|---|
Certification | CE/RED, EAC, ROHS |
