Grandstream GWN7813 24‑Port Layer 3 Managed Network Switch with 4×10G SFP+ Uplinks

Overview

The Grandstream GWN7813 is a high‑performance Layer 3 managed network switch designed for enterprise LAN infrastructure, campus networks, and data‑intensive business environments. It features 24 Gigabit Ethernet ports and 4 high‑speed 10 Gigabit SFP+ uplink ports, delivering powerful throughput for bandwidth‑heavy applications.

With a 128 Gbps switching capacity and up to ~95 Mpps forwarding rate, this Rackmount switch ensures fast, low‑latency performance for VoIP systems, wireless access point backbones, IP surveillance networks, and inter‑VLAN routing.

The GWN7813 supports advanced Layer 3 routing, robust security features, flexible deployment options, and centralized management — making it ideal for modern enterprise networks.

Key Features

• 24 × Gigabit Ethernet RJ45 ports

• 4 × 10 Gbps SFP+ uplinks for high‑speed backbone connectivity

• Layer 3 routing with static and dynamic capabilities (e.g., RIP, OSPF)

• 128 Gbps switching capacity and ~95 Mpps forwarding performance

• Supports up to 4K VLANs and advanced QoS

• Enterprise security features including ARP inspection, IP Source Guard, DHCP snooping, and DoS protection

• Stackable up to 4 units for scalable deployments

• Cloud and local management via GDMS, Web UI, CLI, SNMP

• 1U rackmount design with optional redundant power support

Technical Specifications

Layer 3 & Routing Features

The GWN7813 supports comprehensive Layer 3 functions including:

• Static and dynamic routing such as RIP / RIPng / OSPF / OSPFv3

• Inter‑VLAN routing

• IPv4 and IPv6 dual‑stack support

• Policy‑based routing options

These capabilities allow the switch to act as both a routing and switching core in enterprise environments.

Security & Traffic Management

Enterprise‑grade protection ensures network integrity:

• 802.1X & RADIUS/TACACS+ authentication

• DHCP snooping & ARP inspection

• IP Source Guard & DoS protection

• Storm, loop and broadcast control

• ACL traffic filtering

Advanced QoS, priority queuing, and traffic shaping help optimize performance for critical applications like VoIP and video.

Management Options

Administrators can configure and manage the switch using:

• Web‑based GUI

• Command Line Interface (CLI)

• SNMP v1/v2c/v3 support

• GWN.Cloud centralized cloud management

• GWN Manager on‑premise controller

Flexible management options make it easy to monitor, troubleshoot, and scale deployments.

Ideal Applications

The Grandstream GWN7813 is perfect for:

• Enterprise LAN backbone networks

• Data center edge switching

• VLAN segmentation and routing environments

• Wireless access point aggregations

• VoIP and IP telephony systems

• High‑density CCTV and surveillance infrastructure
