Grandstream GWN7711 – 8-Port Layer 2 Lite Managed Gigabit Network Switch

Product Overview

Boost your business network with the Grandstream GWN7711, an 8-port Layer 2 Lite managed Gigabit switch engineered for reliable, secure, and high-performance connectivity. Designed for small and medium-sized businesses, this switch combines enterprise-grade networking features with simple cloud and web-based management.

Featuring eight Gigabit Ethernet ports, the GWN7711 delivers fast data transfer for IP phones, wireless access points, surveillance cameras, servers, and desktop computers. Intelligent Layer 2 management capabilities help optimize traffic flow while improving network stability across demanding business environments.

Advanced networking functions such as VLAN, Quality of Service (QoS), Link Aggregation, IGMP Snooping, and Loop Detection simplify network segmentation and improve performance for voice, video, and data applications. Comprehensive security features help safeguard connected devices from common network threats.

Flexible deployment options allow installation on a desktop or wall, while the fanless design ensures silent operation, making it ideal for offices, classrooms, hotels, retail stores, and home offices. Convenient management through the local Web UI and Grandstream Device Management System (GDMS) reduces administration time and supports centralized network monitoring.

Key Features

• 8 × 10/100/1000 Mbps Gigabit Ethernet ports
• Layer 2 Lite managed switching
• 16 Gbps switching capacity
• 11.9 Mpps forwarding rate
• Store-and-forward packet forwarding
• Supports up to 32 VLANs
• IEEE 802.1Q VLAN tagging
• Voice VLAN support
• Link Aggregation (LAG)
• Quality of Service (QoS) traffic prioritization
• IGMP Snooping for multicast optimization
• Storm Control for broadcast, multicast, and unicast traffic
• Loop Detection and Loop Prevention
• Cable Test diagnostics
• Port Mirroring
• DHCP Client support
• SNMP monitoring
• LLDP support
• Web-based management interface
• Cloud management via GDMS
• Fanless, whisper-quiet operation
• Desktop and wall-mount installation
• Kensington security slot
• Firmware upgrade and configuration backup/restore support

Technical Specifications

Ideal Applications

• Small and medium-sized businesses
• Corporate offices
• Retail stores
• Hotels and hospitality
• Schools and universities
• Healthcare facilities
• Home offices
• IP surveillance systems
• VoIP deployments
• Wireless access point aggregation
• Structured Gigabit LAN networks

Benefits

Efficient traffic management keeps business applications running smoothly even during peak network usage.

Reliable Layer 2 switching enhances communication between connected devices without sacrificing performance.

Simple cloud-based administration minimizes maintenance while providing centralized visibility into network health.

Silent fanless operation makes the switch suitable for noise-sensitive environments.

Enterprise-level security features help protect business infrastructure against network disruptions.
