D-Link DMC-540SSC Media Converter

7,800.00 KSh +VAT

○ One/Two channel 10/100/1000 Mbps Ethernet to 10/100 Mbps fiber optic conversion
○ Plug-and-Play, no additional software required
○ Half or full-duplex operation

Product Documents

Datasheet

Description

D-Link DMC-540SSC 100Base-TX to 100Base-FX Single-mode Fiber (SC) Media Converter 100Base-TX to 100Base-FX Single-mode Fiber (SC) Media Converter supporting signals up to 550 m apart.


D-Link DMC-540SSC Media converters convert signals that are transmitted from one type of media to another so that they can be transmitted over a different type of media. This series of media converters converts 10/100/1000 Mbps copper Ethernet to a 100/1000 Mbps fiber optic connection connection.This allows you to expand your network by connecting longer distance,cables between devices that are otherwise connected with short distance Ethernet cables, such as Cat.6 twisted-pair cables.

Features of DMC-540SSC

Fast and Easy to Use
○ One/Two channel 10/100/1000 Mbps Ethernet to 10/100 Mbps fiber optic conversion
○ Plug-and-Play, no additional software required
○ Can be used standalone or installed in the DMC-1014 chassis
○ Half or full-duplex operation
○ Auto-MDI/MDIX

Easy Placement and Monitoring
○ Mount up to 14 media converters in the specially designed DMC-1014 Media Converter Chassis
○ Dedicated power supply for powering the chassis and all installed media converters
○ Hot-swappable when mounted
○ Front panel LEDs for instant status feedback

Specification

DMC-540SSC

Interface

Number of Ports

• 1 x 10/100BASE-TX RJ-45 port

1 x 100BASE-FX SC port

Standards

IEEE 802.3 for 10BASE-T/F

IEEE 802.3u for 100BASE-TX/FX

Data Transfer Rate

Ethernet: 10 Mbps/20 Mbps (half- duplex/full-duplex)

Fast Ethernet: 100 Mbps/200 Mbps (half-duplex/full-duplex)

Duplex Mode

Half-duplex/full-duplex

Media Types

10BASE-T: 2-pair Cat. 3/4/5/5e, Unshielded Twisted Pair (UTP) (up to 100 m)

10/100BASE-TX: 2-pair Cat. 5/5e, Unshielded Twisted Pair (UTP) (up to 100 m)

100BASE-FX: Multi-mode fi optic cable with SC connector (up to 40 km)

Media Exchange Interface

Auto-MDI/MDIX

Functionality

Transmission Mode

Store-and-forward

Forwarding Rate

Full wire-speed forwarding rate

Physical

Diagnostic LEDs

• Power

• Speed (for twisted pair ports)

• Full-duplex/Collision (for twisted pair and fi ports)

• LINK/ACT (for twisted pair ports)

AC Input

5 V/1 A external power adapter

Temperature

Operating: 0 °C to 50 °C

Storage: -20 °C to 70 °C

Humidity

5% to 90% RH, non-condensing

Dimensions

95x 70 x 26 mm

Fiber Wavelength

1310 nm

Supported Fiber Cable Length

Up to 40km

Emission Certifi tions (EMI)

FCC
