1m Cat6 Patch Cord

Type: CAT6 Cable
Compatible with Lan cable
HST RJ45 patch cords available Length: 5M, 3M, 2M, 10M and 1M

High performance RJ45 Patch Cord
Conductor:24AWG/26AWG Copper,CCA,CCS 8*7*0.12, 8*7*0.18 etc
Insulation:0.92mm+/- 0.06 HD/PE
Pairs:4 pairs
Shield: PVC LSZH
Packing: 1m,2m,3m,5m,7m,10m,15m,20m…100m
Any length is available
Temperature Range: -20 up to +75c
Conductor Resistance: Max.9.38 ohm/100m
Resistance Unbalance: Max. 2%
Insulation Resistance: Max. 150 ohm/Km
Mutual Capacitance: Max. 5600pF/100m
Capacitance Unbalance: Max. 330pF/100m
Impedence: 100+/-15
Spark Test:2000V
Velocity of propagation: 67%
Specification:
Specification: 4P+F
Rated Temperature: 60°C or 75°C
Unshielded twisted pairs:
Conductor: 26AWG or 24AWG Stranding or Solid Bare copper
Insulation: HD-PEFiller: PE Cross or FM-PE Thin slice
rope: optional
Jacket: PVC or LSNH
Reference standard: YD/T1019-2001,ISO/IEC11801,ANSI/TIA/EIA-568B,UL 444
Print Legend: CM or CMR

Application:
1.Lan Network System
2.Computer Network Distributin System
3.Telecommunication Network System
4.Testing Equipment System
5.CATV System
